10.1 Acoustic Output Reference
Chapter 10
z
Transducers and Intended Applications
EMC Note: Operating the transducer in close proximity to sources of strong electromagnetic elds, such as radio
transmitter stations or similar installations, may lead to temporary degradation or interference visible on the monitor
screen. A lightening of image background may be noticed while visualizing hypoechoic structures, or jitters in the im-
age screen may occur. The transducers that can be connected to the system have been designed and tested to with-
stand such interference, and will not sustain irreversible damage.
Refer to "11.6 Electromagnetic Emissions and Electromagnetic Immunity".
TRANSDUCER NAME SCANNING FREQUENCY MODES OF OPERATION MAIN INDICATIONS FOR USE
CONVEX PROBE C5-2 2 MHz to 5 MHz
B, M, Color Flow, Power, SCF
*1
,
PW Doppler
Abdomen
LINEAR PROBE L18-4 4 MHz to 18 MHz
B, M, Color Flow, Power, SCF
*1
,
PW Doppler, Elastography
*2
Peripheral vascular,
Supercial, Musculoskeletal
SECTOR PROBE S4-2 2 MHz to 4 MHz
B, M, Anatomical M,
Color Flow, Power, 2D-TDI, PW
Doppler, CW Doppler, PW-TDI
Cardiac, Abdomen
LINEAR PROBE L14-4 4 MHz to 14 MHz
B, M, Color Flow, Power, PW
Doppler
Peripheral vascular,
Supercial, Musculoskeletal
ENDOCAVITY PROBE
EC9-3
3 MHz to 9 MHz
B, M, Color Flow, Power, PW
Doppler
Transvaginal
CONVEX PROBE MC10-3 3 MHz to 10 MHz
B, M, Color Flow, Power, PW
Doppler
Peripheral vascular,
Abdomen, Musculoskeletal
LINEAR PROBE L11-3 3 MHz to 11 MHz
B, M, Color Flow, Power, SCF
*1
,
PW Doppler, Elastography
*2
Peripheral vascular,
Supercial, Musculoskeletal
LINEAR PROBE HL18-4 4 MHz to 18 MHz
B, M, Color Flow, Power, SCF
*1
,
PW Doppler
Peripheral vascular,
Supercial, Musculoskeletal
LINEAR PROBE WL13-3 3 MHz to 13 MHz
B, M, Color Flow, Power, SCF
*1
,
PW Doppler, Elastography
*2
Breast,
Supercial, Musculoskeletal
SECTOR PROBE S4-2A 2 MHz to 4 MHz
B, M, Anatomical M,
Color Flow, Power, 2D-TDI, PW
Doppler, CW Doppler, PW-TDI
Cardiac, Abdomen
*1: SCF-mode cannot be used in some units.
*2: Elastography-mode cannot be used in some units.
