1.6 System Conguration and Part Name
Rear panel
The peripheral devices can be connected to the rear panel.
(1) (2) (3) (4) (5)(5)
No. Name Functions
(1) Power connector AC adapter cable inlet
(2) Security lock Security wire installation hole
(3) DVI-D terminal Output terminal for external imaging system
(4) Ethernet connector Output terminal for network transfer of digital images
(5) USB2.0 port USB system connector (2 locations)
