13 Terminal menus
13.20 Menu 15 "Settings"
136
Comprima V 180
Original Operating Instructions 150001053_00_en
5,0V
3,5V
2,5V
1,0V
2,4V 3,5V2,4V
B61
M1
1
15-1
EQ003-106
ü Menu 15-1 “Sensor test” is open.
ü Sensor B61 “Tying 1 (passive)” has been selected.
Saving is only possible if the bar is inside the bottom or top rectangle of the bargraph.
Setting feed position
RP000-043
The distance(X) between the pivot point of the ratchet(1) and the adjusting lever(2) must be
X=285-295mm.
The feed position for net and chamber film wrapping has been optimally set when the feed
rocker arm moves close enough to the stop so that the distance is 5mm, see chapter Chamber
film wrapping "Checking and setting the feed position".
 For net wrapping: Press the key until the actuator for wrapping process moves out
until the dimension X=285-295mm.
 Press .
Æ The set position is saved.
