Terminal menus 13
Menu 15 "Settings" 13.20
Comprima V 180
Original Operating Instructions 150001053_00_en 137
Setting the cutting position
RP000-044
The cutting position has been optimally set when the dimensions are as follows with raised
ratchet mechanism (1):
Dimension X Dimension Y
Net wrapping 410mm 365mm
Chamber film wrapping 400mm 370–375mm
 Press the key or until the tying actuator retracts far enough and the dimensions
X and Y from the table above are achieved.
 Press .
Æ The set position is saved.
Setting the tying position
RP000-045
