6-50 824 Reference Manual 11/8/00
The following explains each of the display’s components:
Display label
- This shows the current display (for example,
“
Excd-a
”)
Exceedance Number
- The
“
Exceedance” display shows
each exceedance record in the order that it occurred. The
exceedance number indicates the order of the displayed
exceedance in relation to the other exceedance records.
Exceedance Date/Time
- The Event Date/Time shows the
time and date that this exceedance occurred.
Leq Reading -
The Leq
Reading shows the Leq for the cur-
rently displayed exceedance.
SEL Reading
- The SEL Reading shows the SEL for the
currently displayed exceedance.
Exceedance Duration
- The Exceedance Duration shows
the length of time this exceedance lasted.
Excd-b Display
The
Excd-b
display consists of six major components:
• Display label
• Exceedance Number
• Exceedance Date / Time
• Peak - I Reading
• Peak - II Reading
• Max Reading
The
Excd-b
display is shown below:
