10-12 824 Reference Manual 11/8/00
•
Time
- The 824 stops recording an Autostore after “End-
Time”.
•
Count
- The 824 stops recording an Autostore after “End
Samples” of data have been received.
End Level
This level is used when the “End Mode” is set to
Level (L<,
L=, L>)
. It is the amplitude in dB at which the 824 will stop
recording an Autostore record.
• 0.0 - 255.9 dB
End Time
The 824 stops recording an Autostore record when the “End
Time” has been satisfied.
• 00.0000 to 99.9975 seconds
End Samples
The 824 stops recording an Autostore after “End Samples”
has been satisfied.
• 0 - 65535
End Logic In
When the “End Mode” is set to
Input,
the 824 stops record-
ing an Autostore record when the logic In line changes to
“End Logic In” state.
•Low
•High
Then Settings Menu
End Then
After the measurement ends, the 824 may do the following:
