Larson Davis System 824 - Modifying and Storing Setups to the 824

11/8/00 Using the 824 Utility Software 9-9
window). The setups are organized and grouped similar to
the 824 menu structure in the instrument. Click on the differ-
ent tabs to access all of the setup parameters.
Modifying and Storing Setups to the 824
NOTE: If you change settings in the Util-
ity program to an active setup in the 824,
those changes will not take effect in the
82 unless the modified setup is re-
selected.
With the 824 Utility software you can make modifications to
any of the user defined setups and the system setup. For
example, in the System setup, you can change any of the
parameters for the Title, Calibration, Power, Date/Time,
Controls or Modem and then send the modified setup to the
824. To store the modified setup, select the
Save Setup to
824
menu item from the
File
menu or click on the
Store
Setup in 824
button on the tool bar.
Changing System Settings
*The Option Settings show what
options were purchased for this
instrument and can’t be changed. To
purchase an option, contact your
Larson Davis represenative.
The system selection on the setup list box contains the gen-
eral settings for the 824. The selections here include, Title,
Options*, Calibration, Power, Date and Time, Controls and
Select different tabs to access
all of the setup functions.
Parameters can be entered manually,
or the pull down selections can be
used.
