11/8/00 Quick Start 4-11
The Setup Menu
Pressing the
S
Setup key will produce a display similar to
the following:
The Active ID
The first item in the list is the Active ID, which will be high-
lighted. If the user exits from the Setup Menu by pressing
either
S
(a second time) or
l
, the instrument is ready to
perform a measurement as defined by that Active ID.
Following the Active ID is a list of the available IDs. In
most cases, the first ID in the list will have the symbol “>” to
the left, indicating that the Active ID was originally defined
by selecting that ID. Thus, the name of the Active ID and
this ID will be the same. If there is an asterisk “*” to the left
of the Active ID, it indicates that modifications have been
made to the Active ID since the selection of the ID below it,
so they may no longer be the same. If there is no asterisk,
then the Active ID and the one below remain identical.
Active ID
Name of original ID
To Next Page
