11/8/00 Using the 824 Utility Software 9-15
If a message window occurs after pressing the
OK
button
like that shown below,
you will have to create a default setup file by following this
procedure:
• Select the permanent setup for the desired instrument
type.
• Under the File menu select “Save setup to a file”.
• In the “Save setup to a file” window type in “default”
under File name and select “Save”.
The new setup is now defined for a particular instrument ID,
and can be modified from the Setup List box. After creating
a new setup, you can store it to a disk file, or send it to the
824.
Renaming an Existing Setup
To rename an existing user defined setup, right click on the
setup in the left hand side of the screen and select
Rename
Setup
from the popup menu.
