Larson Davis System 824 User Manual

7-60 824 Reference Manual 11/8/00
Intervals Check Menu
The intervals displays have three different check menus
depending upon which display you are viewing.
When viewing the displays
Interval-a
through
Interval-e
the
following menu appears after pressing the Check
c
key:
Following is a chart of the check menu with a description of
each menu item:
In the “Leq Spectrum” display press the Check
c
key and
the following menu appears:
Graph
Changes the scaling of the instru-
ment’s SLM history graph
Bandwidth
Selects either 1/1 or 1/3 octave fil-
ters.
Menu Items Purpose
Leq Spectrum Allows you to view the Leq spectral
data
Max/MinSpectra Allows you to view the Max or Min
spectral data
Ln Spectrum Allows you to view the Spectral Ln
data
Locate Locates a specific interval record
Settings Modifies the interval settings
