9-32 824 Reference Manual 11/8/00
Once the data is in the spread sheet program it can be manip-
ulated, stored, and graphed using the standard spreadsheet
functions.
You can also export and/or save the translated data to a text
file, by selecting the
Export Data
menu item from the
File
menu.
Additional Features
Store Histograms for Overall and Interval Data
One of the features of the 824 Utility software is the ability
to store histograms in both the LOG and SSA virtual instru-
ments for overall, interval, and daily data (LOG only).
These settings can only be made
from the 824 Utility software.
To store an interval histogram for the SSA instrument, select
SLM&RTA from the measurement list, click on the “Interval
tab” and check the box by “Store complete Histogram”.
NOTE: Storing interval or daily histograms for the LOG
instrument is done in a similar manner.
