B-24 824 Reference Manual 9/12/00
macro is executed with the G0 or O[ther] 3 commands
which returns the list of defined read variables.
Use the following command syntax to program each desired
read variable and its position in the macro.
Where n is from 1 to 8, indicating the macro position and
var_no is the number of the “R” variable associated with the
position. Use a var_no of “0” to define the last position
when less than eight are desired.
After programming this group read list, the response to G0 is
59.5, 38.6, 102.2; the SPL, L
min
and L
max
.
Setting Commands
The Settings select what functions are enabled and deter-
mine how the measurements are performed. Settings can be
both set (S) and queried (Q). The setting numbers provided
below in the “Setting List” section are for both the Set (S)
and Query (Q) commands.
• Option e.g. [Sun|Mon|Tues…|Sat]
• Numeric e.g. (123.45)
• Character e.g. (Gas Flare, Test 1); can be up to 30 char-
acters
• Template e.g. (hh:mm:ss)
Syntax Response
G[roup]n, var_no <cr><lf>
Example: G1, 4 <cr> assigns the current SPL to the first group option
Example: G2, 15 <cr> assigns Lmin to the second option
Example: G3, 19 <cr> assigns Lmax to the third option
Example: G4, 0 <cr> terminates group command programming
