B-58 824 Reference Manual 9/12/00
For the LOG instrument type H5 and H6 are for when
“Other Level” setting is set to [Advc] to enable the advanced
time history.
Time History Variables (SSA, LOG, TAL)
Brackets in the syntax indicate optional characters and oper-
ands.
Histogram Table Variables
Brackets in the syntax indicate optional characters and oper-
ands.
Table:
• 1=RMS,
• 2=Peak,
• 3=Unweighted Peak.
H
101
SSA, LOG,
TAL
Same as doing an H 1 + H 5, 0
H
102
SSA, LOG,
TAL
Same as doing an H 1 and H 6, 0
Syntax Response
H[istory]var_no time_var
H2 123.4 (Peak level in current record)
H 1 Leq (RMS Level) nnn.n dB ‘n’
H 2 Peak Level nnn.n dB
H 3 Run Time of Sample (calc) hhhhh:mm/hh:mm:ss/mm:ss.ss
H 4 HISTORY BARGRAPH ==========-----
