Larson Davis System 824 User Manual

11/2/00 FFT (Optional) 11-11
Snapshot
Once you have stored an FFT snapshot by accessing “Store
Snapshot” from the FFT check menu, you can view the snap-
shot data by pressing the View
V
key. The following menu
appears:
Highlight “Snapshot” and press the Check
c
key to access
the snapshot data.
Use the up
u
and down
d
arrow keys to scroll through
each record.
Use the check menu to control the HORIZONTAL SCALE.
The
date
and
time
records when the snapshot was taken.
Snapshot Check Menu
To access the snapshot check menu, press the Check
c
key
while viewing the snapshot data. The following menu
appears:
Snapshot number/
Date and time
total number
of snapshots
