11/8/00 Front Panel Keys; their Functions and Menus 3-17
Press the
T
TOOLS key, and the following screen appears:
Permanent IDs (marked with a ‘p’ in
the Setup menu) cannot be write pro-
tected, modified, or deleted.
To write protect (or lock) an ID, use the
u
or
d
keys to
highlight
Write Protect
, and then press the
c
key. A locked
symbol appears next to locked IDs in the Setup menu
(except for the current running ID) and symbolizes that this
ID is “Write Protected”. Once the ID is write protected, it
cannot be changed or deleted until it is “Write Enabled”.
Write protected IDs (marked with a
locked symbol on the Setup menu)
cannot be deleted. The icon will not
be displayed if the currently active
ID is being used. Also, the currently
active ID cannot be deleted.
To delete an ID that has not been write protected, use the
u
or
d
keys to highlight
Delete ID
, then press the
c
key. The ID is removed from memory and the ID name is
removed from the
Setup
menu.
To write enable (or unlock) an ID, use the
u
or
d
keys
from the
Setup
menu to highlight the desired write protected
ID (marked with a locked symbol). Press the
T
TOOLS
key. Press the
c
key on the highlighted
Write Enable
menu
option. The locked symbol
disappears next to the ID shown
in the
Setup
menu, symbolizing that this ID is write enabled.
Tools Key
NOTE: In certain situations you also use
the
T
TOOLS key to delete, write
enable, or write protect instrument defi-
nitions (ID) from the
Setup
menu (as
previously described).
The
T
TOOLS key allows you to access controls and oper-
ations such as calibration, battery usage, memory usage, set-
ting date and time, timer, or computer port settings. You
press the
T
TOOLS key to access the
Tools
menu. To mod-
ify settings press the
r
key on a menu item from the
Tools
menu. Pressing the
c
key on a menu item from the
Tools
menu allows you to view system settings and other
displays.
The ID that is active, with a “>” by
it, cannot be deleted.
