Larson Davis System 824 User Manual

9/12/00 B-59
Default is last used table or RMS.
Print Commands
Brackets in the syntax indicate optional characters.
<cr> = carriage return; <lf> = line feed
Syntax Response
T[able]var_no[, table] table_var
Example: T1,1 -75.0 (RMS current bin level)
T 1 [n
a
] LOG Level of current bin nnn.n dB
T 2 [n] LOG Count of samples nnnnnc (c= K or M for Kilo or
Mega)
T 3 [n] LOG Percent of total nnn.nn%
T 5 [ n] LOG Prints the accumulated time for the
current level/bin. The table number is
optional.
hhhhh:mm:ss.s
T n+64 LOG Shows total of bins less than this level
T
n+128
LOG Shows total of bins greater than this
level, plus resolution
a. Where n equals the table number: 1-RMS, 2-Peak, & 3-UnWeighted Peak.
Syntax Response
P[rint]print_no <cr><lf>
