B-36 824 Reference Manual 9/12/00
Histogram Reports
The RMS, Peak and UWPk histogram reports have been
implemented with this revision. The unformatted reports
have also been developed and the format is the level of the
first bin followed by the number of samples in each bin (in
hex, 0-9 & a–F). There are 1024 RMS bins and 128 Peak
and UWPk bins, this corresponds to 1/8th dB resolution for
RMS and 1dB resolution for the peak tables.
S104 LOG SPL HISTOGRAM TABLE (x)
S105 LOG SPL HISTOGRAM TABLE LOW
VA L UE
(n)
S106 LOG SPL HISTOGRAM TABLE HI
VA L UE
(n)
S107 LOG SPL HISTOGRAM TABLE RESO-
LUTION
(x)
S108 LOG PEAK-II HISTOGRAM TABLE (x)
S109 LOG PEAK-II HISTOGRAM TABLE
LOW VALUE
(n)
S110 LOG PEAK-II HISTOGRAM TABLE HI
VA L UE
(n)
S111 LOG PEAK-II HISTOGRAM TABLE
RESOL
(x)
S112 LOG PEAK-I HISTOGRAM TABLE (x)
S113 LOG PEAK-I HISTOGRAM TABLE LOW
VA LU E
(n)
S114 LOG PEAK-I HISTOGRAM TABLE HI
VA L UE
(n)
S115 LOG PEAK-I HISTOGRAM TABLE
RESOL
(x)
