Larson Davis System 824 User Manual

11/8/00 Using ID Setting Files 7-25
Hist Enable - (LOG, SSA)
This setting provides the following two options:
No -
Time history storage is disabled.
Yes -
Time history storage is enabled.
Hist Period (LOG, SSA)
This setting is used in conjunction
with the “Period Units Setting”
(below).
Hist Period
sets the number of history
period units
that
transpire between successive time history samples. These
samples continue either until the instrument is stopped or
runs out of memory. This setting can include any integer
value in the following range:
(0) to (255)
Period Units - (LOG, SSA) Period Units
selects the type of units the instrument uses to
calculate the time which transpires between successive time
history storage operations. To calculate the timer period, the
instrument multiplies the units selected in this setting by the
number set in
Hist Period
setting (see the previous “Hist
Period” setting and the following example).
Resolution 0.1 dB
1.0 dB
TH Setup Activates a set of 3 displays used to
configure what time history data
will be stored. See page 7-27.
Marker Text Marker 1
(Aircraft)
Marker 2
(Automble)
Marker 3
(Truck)
Marker 4
(Train)
Marker 5
(Animal)
