11/8/00 Introduction 1-13
• Reference Manual (I824.01)
• Serial cable, DB9S to DIN08 (CBL006)
• AC/DC output cable, 1/8" mini phone plug to dual dual
phono or BNC (CBL042)
• Universal AC power adapter. (90 to 264 Vac, 50 to 60
Hz, 12 volt output) (PSA027)
• Hard case 15”x19”x7” (CCS001) with foam insert
(0860.0077)
•Windows
TM
utility software (SWW_824_UTIL)
• 10 foot microphone extension cable (EXA010)
The following
optional
equipment is also available:
• CAL200 Sound Level Calibrator, 1000 Hz @ 94 or 114
dB (IEC 942-1988 Class 1)
• CAL250 Sound Level Calibrator, 250 Hz @ 114 dB (IEC
942-1988 Class 1L)
• Microphone extension cables are available in 1.5, 6, 10,
20, 25, 35, 50, 66, 100, and 200 foot lengths or custom
lengths up to 328 feet.
• Direct BNC microphone input adapter (ADP005)
• External Battery Charger (PSA024) (Used to quick
charge the BAT010)
• Accelerometer preamp for ICP accelerometers
(PRA950-4) provides 4 mA current source. Must have
CBL079 to attach to the 824.
Connecting Internal or External Power
The 824 is shipped with a NiMH bat-
tery pack preinstalled.
The System 824 can be powered using a NiMH battery pack,
alkaline batteries, or an AC power supply adapter. Below we
will discuss how to install and use each.
