7-12 824 Reference Manual 11/8/00
heater output (pin 8, pulled to ground). You can use these
Logic Outputs
to actuate external devices during certain
events or combinations of events that occur in the instru-
ment. The option you select determines which types of
events will trigger a logic output line.
NOTE: In many of the options below,
notice the use of a shorthand identifier
which includes the first letters of the var-
ious events along with the plus + symbol.
The plus symbol indicates a logical
“OR” function between events. In other
words, if for a given option, any one of
the listed events occurs alone or in com-
bination with another event, the logic
output will turn on.
The
Logic Output
setting provides the following options:
Off -
The
Logic Output
is disabled.
RMS -
The
Logic Output
turns on when an RMS
exceedance event occurs. An RMS exceedance
event occurs when the RMS sound pressure level
(SPL) exceeds the threshold set by the
SPL Trig-
ger Level
setting. The Any-Data SPL used is the
one specified by the Weight and Detector settings
Peak -
The
Logic Output
turns on when the
instantaneous peak level (Peak-I) specified by the
Peak Weight setting is over the
Peak-1 Exceed-
ance Level
, or when the instantanous weighted
peak level (Peak-II) specified by the Weight set-
ting is over the
Peak-2 Exceedance level
.
R+P -
The
Logic Output
turns on when either an
RMS or Peak exceedance event occurs.
Intv -
The
Logic Output
turns on when an interval
begins.
R+I -
The
Logic Output
turns on when an RMS
exceedance event occurs or when an interval
begins.
P+I -
The
Logic Output
turns on when any peak
exceedance event occurs or when an interval
begins.
R+P+I -
The
Logic Output
turns on when either
an RMS or peak exceedance event occurs or when
each interval begins.
The A:D (or ‘A’) functions are for
compatibility with systems that have
analog data aquisition, generally
used to record weather metrics.
A:D -
The
Logic Output
turns on when an event
on one of the A:D channels occurs. These A:D
channels are typically used for weather monitor-
ing.
