1-6 824 Reference Manual 11/8/00
• Standard memory (2 MB) sufficient to store one of the
following:
- 30,000 point 1/3 octave SSA Leq time history
- 20,000 intervals with 1/3 octave Leq spectrum
- 12,300 SSA intervals with Leq & Max 1/3
octave spectra
- 60,000 LOG intervals without Ln
- 35,000 LOG intervals with Ln
- 1,000,000 point time history
- 70,000 RTA 1/1 octave spectra
- 28,000 RTA 1/3 octave spectra
- 2400 FFT 400 line snapshots
• AC/DC output, unweighted, with gain to 50 dB and
attenuation to -20 dB
• Flash memory for in-field firmware upgrades
• Multi-tasking processor: provides simultaneous measur-
ing, viewing, transfering and printing of data
• RS-422 (RS-232 compatible) interface:
Serial bit rate to 115 kbps
• Direct report printouts
• Windows
TM
-based software included for setup, control,
and high speed data downloading and translation to
ASCII format
