8-26 824 Reference Manual 9/13/00
NOTE: See the Summary and Tailored
Templates on pages 9-9 to 9-12 for a
description of each report for the SSA
and LOG instruments.
The following table shows the available options under the
Customize
menu for the RTA instrument:
(RTA instrument)
Report
Options Description
Data Report No
Ye s
Name and Address of Company and date printed.
Live No
Ye s
Shows beginning and ending date and time, runtime, type of Averaging,
sample rate, trigger phase ad Live Spectrum.
Leq No
Ye s
Shows beginning and ending date and time, runtime, type of Averaging,
sample rate, trigger phase ad Leq Spectrum.
Max No
Ye s
Shows beginning and ending date and time, runtime, type of Averaging,
sample rate, trigger phase ad Max Spectrum.
Min No
Ye s
Shows beginning and ending date and time, runtime, type of Averaging,
sample rate, trigger phase ad Min Spectrum.
Autostore Rpt No
Short
Long
The
Short
report
prints the Leq, Lmax and Lmin spectrum. In addition,
the ByTime Spectrums are included in the
Long
report.
Lowest Record 0 - 65535 The lowest Autostore Record to print.
Highest Record 0 - 65535 The highest Autostore Record to print.
Lowest ByTime
0 - 65535 The lowest ByTime Spectrum to print.
Highest ByTime
0 - 65535 The highest ByTime Spectrum to print.
RT-60 Report
No
Ye s
Prints the calculated RT60 for every octave or 1/3 octave band.
Avg Hist
No
Ye s
Spatial Average History
Lowest Record
0 - 65535 The lowest Spatial Average History Spectrum to print
Highest Record
0 - 65535 The highest Spatial Average History Spectrum to print
Setup Report
No
Ye s
Print the settings and their values for the RTA instrument.
To Next Page
