11/8/00 RTA (optional) 10-3
The menu layout of the
RTA
settings is shown in the table
below:
Menu Items Submenu Available Settings Options Available Settings Options
Title User customized text entry
RTA
Gain
(dB)
-20
-10
+0
+10
+20
+30
+40
+50
Bandwidth
1/1
1/3
Detector
Lin
Exp
Lin Detc Time 0.0025 to 99.9975 sec
Exp Detc Time
(seconds)
1/32
1/16
1/8
1/4
1/2
1
2
4
8
16
32
64
Exp Store Rate
1/2 second
1/8 second
Transducer
Condnsr
Elctret
Direct
Random Corr
No
Yes
Autostore
Autostore
No
Yes
Pretrigger # 0-400 samples
Save ByTime
No
Yes
Trigger Setup
Triggering
No
Yes
Trigger Source
Any 1/1 or 1/3 octave filter
Flat
