Larson Davis System 824 User Manual

11/8/00 RTA (optional) 10-25
Press the
r
right arrow key to select the available
Autostore summary data views which are Leq, Max, and
Min.
Use the
u up and d down
arrow keys to highlight the desired
display.
Press the
c
check key to view the
Leq
display.
Leq
The autostore
Leq
display shows a bin by bin equivalent
level of all samples while the Autostore is triggered..
To move to the next Autostore display, press the
c
check
key and then the
r
right arrow key.
Display label
Record number
Filter level in dB
Bandwidth (1/1 or 1/3 oct.)
Autostore duration
Autostore occurance date and time
Number of autostore records
Selected filter frequency
