Larson Davis System 824 - Page 442

B-44 824 Reference Manual 9/12/00
S75 RTA Logic Outputs Control Setting (bit
mapped word: 3 outputs X 5 states)
S76 RTA End Mode [Never| L < | L = | Input |
Time | Count]
S77 RTA End Level (nnn.n) dB
S78 RTA End Time (ss.ssss) Sec
S79 RTA End Samples (nnnnn)
S80 RTA End Logic Input TRUE Level [Low |
High]
S81 RTA End Then, Repeat Mode [Stop | Repeat
| Average]
S82 RTA Repeat Count (nnn) 0 to 255 times
S83 RTA Average Count (n) 0 to 9 times
S84 RTA Annunciator (cccccccc) if right digit is
numeric it will auto-increment
S85 RTA RT-60 calculation dB down setting [5 |
10 | 20 | 30]
S86 RTA Horizontal Graph Scaling [1, 2, 3, 4 ... ,
725, 1024]
S188 RTA Print Live Summary or Event Data [No
| Yes]
S189 RTA Print Leq Summary or Event Data [No |
Ye s ]
S190 RTA Print Max Summary or Event Data [No
| Yes]
S191 RTA Print Min Summary or Event Data [No
| Yes]
S192 RTA Event working report enable [No |
Short | Long]
