SDA Operator’s Manual
Deleting All Files in a Folder
1. Touch File in the menu bar, then Disk Utilities... in the drop-down menu.
2. Touch the Delete button
in the "Disk Utilities" dialog.
3. Touch inside the Current folder data entry field and use the pop-up keyboard to enter the
path to the folder that contains the file you want to delete. Or touch the Browse button and
navigate to the folder.
4. Once you have located the folder, touch the Empty Folder button.
Creating a Folder
1. Touch File in the menu bar, then Disk Utilities... in the drop-down menu.
2. Touch the Create button
in the "Disk Utilities" dialog.
3. Touch inside the Current folder data entry field and use the pop-up keyboard to enter the
path to the directory you want to create the folder in, and the name of the folder.
4. Touch the Create Folder button.
PRINTING AND FILE MANAGEMENT
Print, Plot, or Copy
The instrument gives you the ability to output files to a printer or plotter, to print to file, or to e-mail
your files. Any WindowsXP supported printer is supported by your instrument.
Printing
Printer Setup
1. In the menu bar, touch File, then Print Setup... in the drop-down menu. The Utilities
Hardcopy dialog opens.
2. In the dialog area, touch the Printer icon
.
3. Under Colors, touch the Use Print Colors checkbox if you want the traces printed on a white
background. A white background saves printer toner. (You can change the printer colors in
the Preference dialog;)
4. Touch inside the Select Printer field. From the touch pad pop-up choose the printer you want
to print to. Touch the Properties button to see your printer setup.
5. Touch the icon for the layout Orientation you want: portrait or landscape.
6. Touch the Grid Area Only checkbox if you do not need to print the dialog area and you only
want to show the waveforms and grids.
SDA-OM-E Rev H 111
