34 SDA-OM-E Rev H
Pass/Fail Testing
Simultaneously test multiple parameters against selectable parameter limits or pre-defined
masks. Pass or fail conditions can initiate actions including document to local or networked files,
email the image of the failure, save waveforms, send a pulse out of the front panel auxiliary BNC
output, or (with the GPIB option) send a GPIB SRQ.
Advanced Math Package (XMATH) – Standard
This package provides a comprehensive set of signal WaveShape Analysis tools providing insight
into the wave shape of complex signals. Additional capability provided by XMATH includes:
• 8 math traces total (4 additional)
• Parameter math add, subtract, multiply, or divide two different parameters
• Histograms expanded with 19 histogram parameters and up to 2 billion events
• Trend (datalog) of up to 20,000 events
• Track graphs of any measurement parameter
• FFT capability added to include: power averaging, power density, real and imaginary
components, frequency domain parameters, and FFT on up to 25 Mpts
• Narrow-band power measurements
• Auto-correlation function
• Sparse function
• Cubic and Quadratic Interpolation
Jitter and Timing Analysis Package (JTA2) – Standard
This package provides jitter timing and analysis using time, frequency, and statistical views for
common timing parameters, and also includes other useful tools.
• Jitter and timing parameters, with Track graphs for the following:
Cycle-Cycle Jitter
N-Cycle
w/ start selection Frequency
Period
Half Period
Width
Time Interval Error
Setup
Hold
Skew
Duty Cycle
Duty Cycle Error
• Edge@lv parameter (counts edges)
• Histograms expanded with 19 histogram parameters and up to 2 billion events
• Trend (datalog) of up to 20,000 events
• Track graphs of all parameters
• Persistence histogram, persistence trace (mean, range, sigma)
