SDA Operator’s Manual
If you minimize the application, touch the appropriate task bar or desktop icon to maximize it:
Restarting the Operating System
To restart the Windows® operating system, reboot the scope by pressing and holding in the
power switch for 10 seconds (until the system shuts down). Press the power button again to start
the scope.
Removable Hard Drive
The removable hard drive option replaces the standard internal hard drive with a removable hard
drive that is installed at the rear of the scope, in the slot normally occupied by the CD-ROM drive.
The kit includes two hard drives, which can be used interchangeably. It also includes a USB CD-
ROM for loading of new software.
Caution! The Removable Hard Drive Is Not Hot-swappable
To avoid damage to the drive or the oscilloscope, shut off power to the oscilloscope
before you insert or remove the hard drive. Ensure that the protective cover is installed
over the drive at all times.
Proper Orientation of Drive
SDA-OM-E Rev H 55
