Warning
This is a Class A product. In a domestic environment this product may cause radio interference,
in which case the user may be required to take appropriate measures.
Electromagnetic Immunity: EN 61000-4-2/A2:2001* Electrostatic Discharge
(4 kV contact, 8 kV air, 4 kV vertical/horizontal coupling planes)
EN 61000-4-3/A1:2003* RF Radiated Electromagnetic Field
(3 V/m, 80-1000 MHz)
EN 61000-4-4:2004* Electrical Fast Transient/Burst
(1 kV AC Mains, 0.5 kV I/O signal/control)
EN 61000-4-5/A1:2001* Surges
(1 kV AC Mains, 0.5 kV I/O signal/control)
EN 61000-4-6/A1:2001* RF Conducted Electromagnetic Field
(1 kV / 0.5 kV common mode / differential mode - AC Mains)
EN 61000-4-11:2004** Mains Dips and Interruptions
(1 cycle voltage dip, 100% short interruption)
* Meets Performance Criteria "B" limits during the disturbance; product undergoes a temporary
degradation or loss of function of performance which is self recoverable.
** Meets Performance Criteria "C" limits during the disturbance; product undergoes a temporary
degradation or loss of function of performance which requires operator intervention or system
reset.
Low Voltage
Directive:
EN 61010-1:2001
Safety requirements for electrical equipment for measurement, control, and
laboratory use.
The oscilloscope has been qualified to the following EN 61010-1 limits:
Installation Categories II (Mains Supply Connector) & I (Measuring Terminals)
Pollution Degree 2 (Normally only dry non-conductive pollution occurs.
Occasionally a temporary conductivity caused by condensation must be
expected.)
Protection Class I (Provided with terminal for protective ground)
UL and cUL Certifications: UL Standard: UL 61010-1 2
n
Edition
Canadian Standard: CSA-C22.2 No. 61010-1-04
Physical Dimensions
• Dimensions (HWD): 264 mm x 397 mm x 491 mm; 10.4" x 15.6" x 19.3" (height excludes
feet); SDA 18000/13000/11000/9000: 310 mm x 447 mm x 500 mm, 12.2" x 17.6" x 19.7
• Weight: 18 kg; 39 lbs. (SDA 6020: 23 kg; 49 lbs.)
• Shipping Weight: 24 kg (53 lbs.); SDA 6020, 4020: 29 kg (63 lbs.); SDA
18000/13000/11000/9000: 36 kg, (80 lbs.)
38 SDA-OM-E Rev H
