SDA Operator’s Manual
Warranty and Service
3-year warranty; calibration recommended annually.
Optional service programs include extended warranty, upgrades, and calibration services.
Optical Reference Receiver (with OE425/OE455)
4th order Bessel-Thompson filter response at the following data rates:
SDA 3010/4000A/4020/5000A/6020/
6000A/9000/11000/13000/18000
SONET/SDH
OC-1/STM0 (51.84 Mb/s)
OC-3/STM1 (155.52 Mb/s)
OC-12/STM4 (622.08 Mb/s)
OC-48/STM16 (2488.3 Mb/s)
Fibrechannel
FC133 (132.7 Mb/s)
FC266 (265.6 Mb/s)
FC531 (531.2 Mb/s)
FC1063 (1063.5 Mb/s)
FC2125 (2127 Mb/s)
Gigabit Ethernet
1.25 Gb/s
InfiniBand
2.25 Gb/s (2127 Mb/s)
User-Defined
Any rate up to 3.5 Gb/s
Software Clock Recovery System
SDA 4000A/SDA 5000A/SDA 6000A
Channel
Software-based clock recovery using golden PLL for data rates
up to 3.5 Gb/s
PLL Bandwidth
Single pole w/ adjustable cut-off frequency
Jitter
Same as time base: 1ps rms
SDA-OM-E Rev H 39
