6. Touch inside the File Name data entry field and enter a name for the display image, using
the pop-up keyboard.
7. Touch the Grid Area Only checkbox if you do not need to print the dialog area and you only
want to show the waveforms and grids.
8. Touch the Print Now button.
E-Mail
The instrument also gives you the option to e-mail your screen images, using either the MAPI or
SMTP protocols. Before you output to e-mail from the Utilities dialog, you first have to set up the
e-mail server and recipient address in Preference Setup.
Sending E-mail
1. In the menu bar touch Utilities, then Utilities Setup... in the drop-down menu.
2. Touch the Hardcopy tab, then the E-mail button.
3. Touch inside the File Format data entry field and select a graphic file format from the pop-up
menu.
4. Under Colors, touch the Use Print Colors checkbox if you want the traces printed on a white
background. A white background saves printer toner.
5. Touch the Prompt for message to send with mail checkbox if you want to include remarks
with the image.
6. Touch inside the Hardcopy Area field and make a selection from the pop-up menu:
7. Touch the Print Now button:
Aux Output
Please refer to Auxiliary Output Signals section of this manual.
Date & Time
The instrument provides the choice of manually setting the time and date or getting it from the
Internet. If you elect to get the time and date from the Internet, you need to have the scope
connected to the Internet through the LAN connector on the rear panel. You can also set time
zones and Daylight Savings time.
Setting the Time and Date Manually
1. In the menu bar touch Utilities, then Utilities Setup... in the drop-down menu.
2. Touch the Date/Time tab.
3. Touch inside each of the Hour, Minute, Second, Day, Month, and Year data entry fields and
enter a value, using the pop-up numeric keypad.
4. Touch the Validate Changes button.
212 SDA-OM-E Rev H
