SDA Operator’s Manual

4. In the "Px" dialog, touch the math on parameters button . The Source field will

expand to two fields.

5. Touch inside the Source1 and Source2 fields and select the parameters you want to apply

math to (P1 to Px). If you are applying math to a single parameter (for example, invert), just

touch inside the Source1 field and select a parameter (P1 to Px).

6. Touch inside the Math Operator field and select

P Script from the Select

Measurement menu.

7. In the "Script Math" dialog, touch inside the Script Language field and select either VBScript

or JScript from the pop-up menu.

8. Touch the Edit Code button; the Script Editor window opens. You can enter code in this

window or call up an existing script from a file storage location. If you create your script in this

window, you can then export it and save it to file.

Measure Gate

Using Measure Gate, you can narrow the span of the waveform on which to perform parameter

measurements, allowing you to focus on the area of greatest interest. You have the option of

dragging the gate posts horizontally along the waveform, or specifying a position down to

hundredths of a division. The default starting positions of the gate posts are 0 div and 10 div,

which coincide with the left and right ends of the grid. The gate, therefore, initially encloses the

entire waveform.

Note: If you have Grid On Top enabled, you will not see the gate posts in their default position at each end of the grid. But

if you touch either end of the grid, a drag cursor will appear, indicating that you have control of the post and can

now drag it.

SDA-OM-E Rev H 145
