7. At the far right of the "Display" dialog, touch inside the Display mode field, and make a

selection from the pop-up menu.

8. Touch inside the Num seg displayed field and enter a value from 1 to 80, using the pop-up

numeric keypad.

9. Touch inside the Starting at field and enter a starting segment number, using the pop-up

numeric keypad.

Sequence Display Modes

The instrument gives you a choice of five ways to display your segments:

Adjacent

Waterfall (cascaded)

Mosaic (tiled)

64 SDA-OM-E Rev H
