Memory
• SDA 6020/4020: 20 Mpts/Ch. Option SDA-XL: 25 Mpts/Ch, 50 Mpts/Ch for 2 or 1
• Ch.SDA6000A XXL/SDA4000A XXL: 50 Mpts/Ch, 100 Mpts/Ch for 2 or 1 Ch
• SDA3010: 10 Mpts/Ch, 20 Mpts/Ch for 2 or 1 Ch. Option SDA-XL: 25 Mpts/Ch, 50 Mpts.Ch
for 2 or 1 Ch.
SDA 18000/13000/11000/9000
SDA 18000 SDA 13000/11000 SDA 9000
18 GHz/Ch
Mode
11 GHz/Ch
Mode
6 GHz/Ch
Mode
13/11 GHz/Ch
Mode
6 GHz/Ch
Mode
9 GHz/Ch
Mode
6 GHz/Ch
mode
Channels 1 1 4 2 4 2 4
Std Memory 60M 40M 20M 40M 20M 40M 20M
XL Memory Option 150M 100M 50M 100M 50M 100M 50M
Acquisition Modes
• Random Interleaved Sampling (RIS): 200 GS/s for repetitive signals (SDA
18000/13000/11000/9000: RIS mode is available in 6 GHz mode only)
• Single-Shot: For transient and repetitive signals: 20 ps/div to 1000 s/div; (SDA
18000/13000/11000/9000 in 6 GHz mode only): 20 ps/div to 1 µs/div
• Sequence: 2 to 40,000 segments (number of segments depends upon memory options)
• Intersegment Time: 6 µs (typical)
Acquisition Processing
• Averaging: Summed averaging to 1 million sweeps; Continuous averaging to 1 million
sweeps
• Enhanced Resolution (ERES): From 8.5 to 11 bits vertical resolution
• Envelope (Extrema): Envelope, floor, roof for up to 1 million sweeps
Triggering System
• Modes: Normal, Auto, Single, and Stop
• Sources: Any input channel, External, EXT X10, EXT/10, or line; slope and level unique to
each source (except line trigger; disabled channels cannot be used as a trigger source in
SDA 18000, SDA13000, SDA 11000, or SDA 9000 when operating in 18 GHz, 13 GHz, 11
GHz, or 9 GHz modes.)
• Coupling Modes: DC
• Pre-trigger delay: 0 to 100% of memory size (adjustable in 1% increments)
• Post-trigger delay: smaller of 0 to 10,000 divisions or 86400 seconds
• Hold-off by time or events: Up to 20 s or from 1 to 99,999,999 events
• Internal trigger range: ±4.1 div from center
• Max. trigger frequency: Up to 5 GHz with Edge Trigger; 750 MHz with SMART Trigger
