Printing
You can print in one of three ways:
• Press the printer button on the front panel:
• In the menu bar, touch File, then Print in the drop-down menu.
• Touch the Print Now button in the "Hardcopy" dialog
Adding Printers and Drivers
Note: If you want to add a printer driver, the driver must first be loaded on the scope.
1. In the menu bar, touch File, then Print Setup... in the drop-down menu. The Utilities
Hardcopy dialog opens.
2. In the dialog area, touch the Printer icon
.
3. Touch the Add Printer button. An MS Windows® window with which to add a printer will
open.
4. Touch the Properties button to change printer properties such as number of copies.
Changing the Default Printer
1. If you want to change the default printer, minimize the instrument application by touching File
in the menu bar, then Minimize in the drop-down menu.
2. Touch the Start button in the task bar at the bottom of the screen.
3. Select Settings, then Printers.
4. Touch the printer you want to set as the default printer, then touch File, Set as Default
Printer.
Managing Files
Use the instrument's utilities to create waveform files on floppy disk, internal hard drive or network
drives. You can copy files from your hard drive to floppy disk. You also can give your files custom
names and create directories for them.
Hard Disk Partitions
The instrument's hard disk is partitioned into drive C: and drive D:. Drive C: contains the
Windows operating system and the instrument application software. Drive D: is intended for data
files.
112 SDA-OM-E Rev H
