SDA Operator’s Manual

SDA-OM-E Rev H 309

STANDARD MODE

Gigabit Ethernet 1000Base-CX TX normalized/absolute, RX

Gigabit Ethernet (optical long-haul) 1000Base-

Gigabit Ethernet (optical short-haul) 1000Base-

10GBase-LX4 TX normalized

DVI Transmitter, receiver low, receiver high, cable

test low, cable test high

Fibrechannel (optical) FC2125, FC1063 TX normalized

Fibrechannel (electrical) FC531, FC266, FC133 TX normalized, TX absolute, receiver

IEEE1394b 400 beta TP2 absolute, 400 beta TP2

normalized, 400 beta receive

Infiniband 2.5 Gb/s Transmitter

RapidIO serial 3.125Gb/s TX (long haul/short haul), Rx

2.5Gb/s TX (long haul/short haul), Rx

1.25Gb/s TX (long haul/short haul), Rx

SONET OC-1, OC-3, OC-12, OC-48, STS-1 eye, STS-3

transmit, STS-3 interface

SDH STM-1, STM-4, STM-16

PCI Express TX add-in transition, TX add-in de-emphasized,

TX system transition, TX system de-

emphasized, RX

Serial ATA 1.5 Gb/s TX connector, RX connector

USB2.0 TX (near end/far end), RX (near end/far end),

TX driver output, RX receiver input

XAUI Driver far, Driver near

Table 2. Standard Masks Included with Option SDM

Jitter Wizard

The Jitter Wizard is a unique feature available with the ASDA-J option that automatically

configures the SDA for optimal jitter measurement. As you provide information regarding the

signal under test, the instrument selects the most appropriate settings. The wizard adjusts the

sampling rate, memory depth, and vertical scale; and adds additional interpolation to the signal

where appropriate.
