2. Touch inside the Format field and select a report format from the pop-up menu
.
3. Touch the Create Report button.
4. A dialog box opens in which to name the report and select a folder to contain the report.
Touch inside the File name field and enter a name using the pop-up keyboard.
5. If you want to e-mail or print the data to a network printer, touch More Actions, then the
Print or E-Mail button. If you select Print, a Windows dialog box will open for you to select a
printer and set options. If you select E-Mail, the report will be sent immediately to the e-mail
address configured in Utilities Preferences.
Formatting the Report
LeCroy provides a default report format (template); however, you can use your own format,
including company logo.
1. Touch the Advanced tab.
2. Touch inside the Directory field and navigate to a folder to contain the reports.
3. Touch the Browse button next to Template to navigate to an existing report format that you
want to use. Or touch inside the Template field and enter the name and path to the template,
using the pop-up keyboard. Otherwise, touch the Use Default checkbox to use LeCroy's
format.
4. To use a logo other that the one provided, which indicates the scope that produced the
report, browse to the bit map file or touch inside the Logo field and enter the name and path
to the file, using the pop-up keyboard. Otherwise, touch the Use Default checkbox to use
LeCroy's logo
.
Note: If you elect to use your own logo bit map, do not use a bit map larger than 180 pixels (height) x 100 pixels (width).
300 SDA-OM-E Rev H
