36 SDA-OM-E Rev H
Analog Persistence Display
• Analog & Color-Graded Persistence: Variable saturation levels; stores each traces
persistence data in memory.
• Persistence Selections: Select analog, color, or three dimensional.
• Trace Selection: Activate Analog Persistence on all or any combination of traces.
• Persistence Aging Time: Select from 500 ms to infinity.
• Sweeps Displayed: All accumulated, or all accumulated with last trace, highlighted
Zoom Expansion Traces
Display up to 8 Math/Zoom traces.
CPU
• Processor: Intel® Pentium 4 @ 2.53 GHz (or better) with MS Windows® XP Platform
• Processing Memory: Up to 2 Gbytes
Internal Waveform Memory
M1, M2, M3, M4 Internal Waveform Memory (Store full-length waveforms with 16 bits/data point.)
Or store to any number of files limited only by data storage media.
Setup Storage
Front Panel and Instrument Status Save to the internal hard drive, floppy drive or to a USB-
connected peripheral device.
Interface
• Remote Control: Via Windows Automation, or via LeCroy GPIB command set
• GPIB Port: (Optional) Supports IEEE-488.2
• Ethernet Port" 10/100Base-T Ethernet interface
• USB Ports: 4 USB ports support Windows compatible devices.
• External Monitor Port: Standard 15-pin D-Type SVGA-compatible
• Parallel Port: 1 standard
Auxiliary Output
• Signal Types: Select from calibrator or control signals output on front panel.
• Calibrator Signal: 5 Hz to 5 MHz square wave or DC Level; 0.0 to +0.5 Volts into 50 (0 to
1 V into 1 M), or TTL Volts (selectable)
• Control Signals: Trigger enabled, trigger out, pass/fail status
Auxiliary Input
Signal Types: Select from External Trigger or External Clock input on front panel.
