SDA Operator’s Manual
Slice2Persist
Note:
This function can only be used in the Web Ed
it mode, available with the XWEB option.
The
Include virtual edges
checkbox
must be checked in the TI
E@lvl
parameter dialog to includ
e both
transition and non-transitio
n edges in
the eye pattern.
