LeCroy SDA User Manual

SDA SPECIFICATIONS
Note: Specifications are subject to change without notice.
Vertical System
SDA 6000/6000A/6020 SDA 5000/5000A SDA 4000A/4020 SDA 3010
Analog Bandwitdth
at 50 Ω (-3 dB)
6 GHz 5 GHz 4 GHz 3 GHz
Rise Time
(10-90% Typical)
75 ps 90 ps 105 ps 150 ps
Rise Time
(20-80% Typical)
NA NA NA NA
Number of Input
Channels
4 4 4 4
Bandwidth
Limiters
20 MHz, 200 MHz, 1 GHz,
3 GHz, 4 GHz
20 MHz, 200 MHz, 1
GHz, 3 GHz, 4 GHz
20 MHz, 200 MHz, 1
GHz, 3 GHz
20 MHz, 200
MHz, 1 GHz
SDA 18000 SDA 13000 SDA 11000 SDA 9000
Analog
Bandwitdth at
50 Ω
(-3 dB)
18
GHz
11
GHz
6 GHz 13 GHz 6 GHz
11
GHz
6 GHz 9 GHz 6 GHz
Rise Time
(10-90%
Typical)
27 ps
40
ps
75 ps 35 ps 75 ps 40 ps 75 ps 49 ps 75 ps
Rise Time
(20-80%
Typical)
19 ps
28
ps
NA 25 ps NA 28 ps NA NA NA
Number of
Input
Channels
1 1 4, 2, or 1 2 or 1 4 or 2 or 1 2 or 1 4 or 2 2 or 1 4 or 2
Bandwidth
Limiters
Full Full
20 MHz,
200 MHz,
1 GHz, 3
GHz, 4
GHz
Full
20 MHz,
200 MHz,
1 GHz, 3
GHz, 4
GHz
Full
20 MHz,
200
MHz, 1
GHz, 3
GHz, 4
GHz
Full
20 MHz, 200
MHz, 1 GHz,
3 GHz, 4
GHz
• Input Impedance: 50  ±2%
• Input Coupling: DC, GND (SDA 3010: DC, GND, DC 1M, AC 1M)
•
Maximum Input: ±4 V
peak
(±5 V
rms
)
• Vertical Resolution: 8 bits; up to 11 bits with enhanced resolution (ERES)
• Sensitivity: 2 mV to 1 V/div, < 10 mV/div through zoom
• DC Gain Accuracy: ±1.5% of full-scale
• Offset Range (excluding SDA 3010): ±750 mV (or more) @ 2 mV to 195 mV/div; ±4 V @
195 mV to 1 V/div
• Offset Range (SDA 3010): ±700 mV @ 2-4.99 mV/div, ±1.5 V @ 5-100 mV/div, ±10 V @
0.102-1 V/div (@ 50 ), ±20 V @ 0.102-2 V/div (@ 1 M)
28 SDA-OM-E Rev H
