Parameter Description Definition Notes
Dtime@level t at level: Computes transition
between selected levels or
sources.
Time between
transition levels of
two sources, or from
trigger to transition
level of a single
source
This measurement
gives the time of the
source 2 edge minus
the time of the source
1 edge.
Reference levels and edge-
transition polarity can be
selected. Hysteresis argument
used to discriminate levels
from noise in data.
Standard parameter.
Dtrig Time Time from last trigger to this trigger Standard in WaveRunner
6000A, WavePro 7000A,
WaveMaster, and sampling
scopes.
Duration For single sweep waveforms, dur is
0; for sequence waveforms: time
from first to last segment's trigger;
for single segments of sequence
waveforms: time from previous
segment's to current segment's
trigger; for waveforms produced by
a history function: time from first to
last accumulated waveform's
trigger.
Time from first to last
acquisition: for
average, histogram or
sequence waveforms
Standard parameter.
Duty@level Percent of period for which data
are above or below a specified
level.
Reference levels and edge-
transition polarity can be
selected. Hysteresis argument
used to discriminate levels
from noise in data.
Available with JTA2 and
XMAP options.
Duty cycle Duty cycle: Width as percentage of
period.
width/period Standard parameter.
Dwidth@level Difference of adjacent width above
or below a specified level.
Reference levels and edge-
transition polarity can be
selected. Hysteresis argument
used to discriminate levels
from noise in data.
Available with JTA2 and
XMAP options.
Standard in SDA100G scopes.
158 SDA-OM-E Rev H
