SDA Operator’s Manual
Parameter Description Definition Notes
Hist maximum Value of the highest (right-most)
populated bin in a histogram.
Available with DDM2, JTA2,
XMATH, XWAV, CAN02, SDA,
and XMAP options.
Standard in DDA-5005A,
SDA100G, WaveExpert, and
sampling scopes.
Hist Max Pop Peak with maximum population in a
histogram.
Available with DDM2, JTA2,
XMATH, XWAV, CAN02, SDA,
and XMAP options.
Standard in DDA-5005A,
SDA100G, WaveExpert, and
sampling scopes.
Hist mean Average or mean value of data in
the histogram.
Available with DDM2, JTA2,
XMATH, XWAV, CAN02, SDA,
and XMAP options.
Standard in DDA-5005A,
SDA100G, and WaveExpert
scopes.
Hist median Value of the "X" axis of a histogram
that divides the population into two
equal halves.
Available with DDM2, JTA2,
XMATH, XWAV, CAN02, SDA,
and XMAP options.
Standard in DDA-5005A,
SDA100G, WaveExpert, and
sampling scopes.
Hist minimum Value of the lowest (left-most)
populated bin in a histogram.
Available with DDM2, JTA2,
XMATH, XWAV, CAN02, SDA,
and XMAP options.
Standard in DDA-5005A,
SDA100G, and WaveExpert
scopes.
Hist Mode Position of the highest histogram
peak.
Available with DDM2, JTA2,
XMATH, XWAV, CAN02, SDA,
and XMAP options.
Standard in DDA-5005A,
SDA100G, WaveExpert, and
sampling scopes.
Hist Pop@X Population at bin for specified
horizontal coordinate. You can
place the cursor at any bin and use
either Absolute, Reference, or
Difference cursor shape.
Available with DDM2, JTA2,
SDM, XMATH, XWAV,
CAN02, SDA, and XMAP
options.
Standard in DDA-5005A,
SDA100G, and sampling
scopes.
SDA-OM-E Rev H 163
