SDA Operator’s Manual
5. Touch inside the Compare Values field and select All or Any from the pop-up menu
.
By selecting All, the test is true only if every waveform falls within the set limit. By selecting
Any, the test is be true if just one waveform falls within the limit.
6. Touch inside the Condition field in the "ParamCompare" mini-dialog and select a math
operator from the pop-up menu:
7. Touch inside the Limit field and enter a value, using the pop-up numeric keypad. This value
takes the dimensions of the parameter that you are testing. For example, if you are testing a
time parameter, the unit is seconds. If you chose either WithinDeltaPct
or
WithinDeltaAbs
from the Condition menu, you also have the choice of setting the
limit by means of the statistical buttons at the bottom of the "ParamCompare" dialog:
SDA-OM-E Rev H 207
