EyeDiagramSetupandMeasurements

1. Select Mask for each Eye Diagram - Depending on the Standard selected, there may be one

or several types of serial data masks available.

2. Select a Mask Margin (as % of the nominal mask size) if desired.

3. Select a Measurement Type. There are three groups of parameters:

Amplitude

• Eye Height

• One Level (Eye)

• Zero Level (Eye)

• Eye Amplitude

Timing

• Eye RiseTime

• Eye FallTime

Eye

• Eye Width

• Eye RMS Jit

• Eye BER

• Eye Crossing

• Avg Pwr (Eye)
