15 Parameter reference
15.2 Parameter list
1008
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00840
Parameter | Name:
C00840 | 16-bit inputs I/O level [%]
Data type: INTEGER_16
Index: 23735
d
= 5CB7
h
Display in percent of 16 bit input values of various blocks of the I/O level
• Non-listed subcodes are "reserved".
Display range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Info
C00840/1 LS_AnalogOutput
: nOut1_a (V)
C00840/2 LP_CanOut1
: wState
C00840/3 LP_CanOut1
: wOut2
C00840/4 LP_CanOut1
: wOut3
C00840/5 LP_CanOut1
: wOut4
C00840/6 LP_CanOut2
: wOut1
C00840/7 LP_CanOut2
: wOut2
C00840/8 LP_CanOut2
: wOut3
C00840/9 LP_CanOut2
: wOut4
C00840/10 LP_CanOut3
: wOut1
C00840/11 LP_CanOut3
: wOut2
C00840/12 LP_CanOut3
: wOut3
C00840/13 LP_CanOut3
: wOut4
C00840/14 LS_DisFree_a
: nDis1_a
C00840/15 LS_DisFree_a
: nDis2_a
C00840/16 LS_DisFree_a
: nDis3_a
C00840/17 LS_DisFree_a
: nDis4_a
C00840/18 LS_DisFree
: wDis1
C00840/19 LS_DisFree
: wDis2
C00840/20 LS_DisFree: wDis3
C00840/21 LS_DisFree
: wDis4
C00840/22 LP_MciOut
: wState
C00840/23 LP_MciOut: wOut2
C00840/24 LP_MciOut
: wOut3
C00840/25 LP_MciOut
: wOut4
C00840/26 LP_MciOut
: wOut5
C00840/27 LP_MciOut
: wOut6
C00840/28 LP_MciOut
: wOut7
C00840/29 LP_MciOut
: wOut8
C00840/30 LP_MciOut
: wOut9
C00840/31 LP_MciOut
: wOut10
C00840/32 LP_MciOut
: wOut11
C00840/33 LP_MciOut
: wOut12
C00840/34 LP_MciOut
: wOut13
C00840/35 LP_MciOut
: wOut14
C00840/36 LP_MciOut
: wOut15
C00840/37 LP_MciOut
: wOut16
C00840/38 LS_AnalogOutput
: nOut2_a (V)
