6I/O terminals
This chapter provides information on the function, possible parameter settings, and technical data
of the input/output terminals of the inverter.
In the »Engineer«, the input and output terminals are parameterised on the Terminal assignment
tab. To do this, go to the Control terminals list field and select the terminals that you wish to
parameterise:
You can find further information in the respective subchapter:
Digital input terminals
( 323)
Digital output terminals
( 344)
Analog terminals
( 347)
Touch probe detection
( 357)
Tip!
How you can alter the preconfigured assignment of the input and output terminals is
described in the chapter entitled "User-defined terminal assignment
". ( 365)
Note!
The input and output terminals of the inverter have already been functionally assigned
in the default setting ("Lenze setting"). The preconfigured assignment depends on the
technology application selected in C00005
and the control mode selected in C00007:
• TA "Actuating drive speed": Terminal assignment of the control modes
( 385)
• TA "Table positioning":
Terminal assignment of the control modes ( 449)
• TA "Switch-off positioning": Terminal assignment of the control modes
( 475)
Wiring diagram, assignment and electrical data of the input and output terminals can be
found in the hardware manual 8400 in the chapter "technical data". The hardware
manual is stored in electronic form on the data carrier supplied with the 8400 inverter.
