17.1.113 L_Not_3
This FB negates a BOOL data type signal.
Inputs
Outputs
17.1.114 L_Not_4
This FB negates a BOOL data type signal.
Inputs
Outputs
Designator
Data type
Value/meaning
bIn
BOOL
Input signal
Designator
Data type
Value/meaning
bOut
BOOL
Result of the NOT operation (negated input signal)
/B1RWB
E,Q E2XW

Designator
Data type
Value/meaning
bIn
BOOL
Input signal
Designator
Data type
Value/meaning
bOut
BOOL
Result of the NOT operation (negated input signal)
/B1RWB
E,Q E2XW

