17.1.73 L_DFSET_1
This FB prepares the master value for a slave drive. This FB enables the inverter to follow the master
drive true to speed and angle.
• You can select values for the stretch factor and gearbox factor of the slave.
• A speed trimming or angular trimming is possible.
Inputs
Designator
Data type
Information/possible settings
dnDeltaPosIn_p
DINT
Input for considering a following error for the mark correction
• The value of this input is used for the following error compensation if the
nNAct_v input is not assigned.
bZeroPulse
BOOL
Enable of the zero pulse-/touch probe synchronisation for the modes 2, 10 ... 13
• The mode is selected in C01075/1
.
FALSETRUE
TRUE
Synchronisation enabled.
bActTPReceived
BOOL
Input for detecting an actual value touch probe or zero pulse
FALSETRUE Actual value touch probe or zero pulse received.
bSetTPReceived
BOOL
Input for status signal "Touch probe detected"
FALSETRUE Touch probe or zero pulse received.
dnActTPPos_p
DINT
Input for accepting the position measured via touch probe at bActTPReceived
dnSetTPPos_p
DINT
Input for accepting the position measured via touch probe at bSetTPReceived
nSpeedTrim_a
INT
Speed trimming in [%]
• Scaling: 16384 ≡ 100 %
