5.4.2 Basic settings
The "Initial commissioning steps" listed in the table below are sufficient for a simple characteristic
control.
• Detailed information on the individual steps can be found in the following subchapters.
 Tip!
Information on the optimisation of the control mode and the adaptation to the real
application is provided in chapter "Optimising the control mode
". ( 163)
Parameterisable additional functions are described correspondingly in the chapter
"Parameterisable additional functions
". ( 258)
Initial commissioning steps
1 Defining the V/f characteristic shape
. ( 161)
2. Defining current limits (Imax controller)
. ( 162)
