17 Function library
17.1 Function blocks | L_ConvPA_1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
17.1.42 L_ConvPA_1
This FB converts a position into an analog value.
Inputs
Outputs
Parameters
Function
Designator
Data type
Information/possible settings
dnIn_p
DINT
Input signal
Designator
Data type
Value/meaning
nOut_a
INT
Output signal
• Internal limitation to ±199 % (100 % ≡ 16384)
Parameters Possible settings Info
C01046/1
0 31 Division factor
•Lenze setting: 1
 Note!
Conversion is remainder considered.
/B&RQY3$B
GQ,QBS Q2XWBD

&

 

nOut_a dnIn_p
1
2
C01046/1
------------------------
⋅=
